SAMPLE ROOM/SECONDARY CUTTING PROCESS CORRECTION

Model: GC850SCCD-P-EP

All-in-one portable oscillating knife cutting machine specialized for secondary edge trimming (re-cutting) of cut pieces

Equipped with the SCCD Vision recognition system, capable of identifying and tracking patterned materials with high precision.also features a projection preview positioning system that ensures accurate alignment and simplified visual recognition for enhanced cutting precision.



Specification Paramete



The right cutter for every segment

Perfection in all details
AI Vision Recognition System
AI Vision Recognition System
Intelligently recognize the contours or feature points of various types of materials, thereby achieving precise positioning and cutting.
12
Reasonable design
Outline putting materials device, ensure operational safety, save time of feeding materials, non-stop operation to increase capacity; Intelligent interactive working table, left and right plate in and out at the same time, or left & right push plate, cutting area can be divided or common.
Smart nesting system
Smart nesting system
The intelligent nesting system for regular materials features automatic counting and nesting; it can intelligently nest multi-part graphics to save material. It supports ultra-long continuous nesting of the same graphic in both positive and negative crossover patterns, thereby improving material utilization.
CCD VisionScan System
CCD VisionScan System
High-precision vision recognition capability, capable of accurately identifying various small pieces, assisting the cutting system to complete the cutting and punching of all types of materials.
Projection preview positioning
Projection preview positioning
By means of projection preview, accurately achieve the positioning and cutting of pieces.
Full scene application
Full scene application
Integrated, movable, enclosed design is suitable for development center and sample room application development, laboratory, studio, profile cutting of processed pieces/sheet(change knife) and other application scenarios.
2
Integrated move portability
With brake move wheel, easy to move with brake wheel, with built-in suction fan and air compressor.
Safety gates
Safety gates
Equipped with a safety light curtain, it can effectively improve the operational safety of personnel.
IoT Bridge
IoT Bridge
Achieve control over the entire smart workshop through digitalization, break down data silos, and improve production efficiency and equipment maintenance.
1
Partitioned vacuum system
Partitioned vacuum system is suitable for any kind of materials. It can effectively fix the material, ensure cutting quality. While also having energy saving design.
Automatic feeding device
Automatic feeding device
Automatic feeding and receiving in one, greatly improving the cutting efficiency and doubling the capacity again.
Emergency stop device
Emergency stop device
When the machine is in an emergency, the voltage is cut off by the emergency stop switch, so that the equipment stops running.
